Photo #: 19-N-104890
Camouflage Measure 32, Design 3D(ex)
Drawing prepared by the Bureau of Ships for a camouflage scheme intended for escort ships of the Buckley (DE-51) class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 7 September 1944. It shows the ship's starboard side, horizontal surfaces and superstructure ends.
Note that this camouflage scheme calls for painting the ship's port side in the lighter tones of Measure 33.
Photograph from the Bureau of Ships Collection in the U.S. National Archives.
