Photo #: 19-N-104910

Camouflage Measure 32, Design 3D


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for destroyers of the Porter/Selfridge (DD-357) class.
This plan, approved by Captain Torvald A. Solberg, USN, probably dates from about mid-1944. It shows the ship's starboard side, horizontal surfaces and superstructure ends.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 132KB; 1200 x 725 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
