Photo #: 19-N-73633

Camouflage Measure 33, Design 14L


Drawing prepared by the Bureau of Ships for a camouflage scheme intended for landing craft, support (large) of the LCS(L)-3 class.
This plan, approved by Captain Torvald A. Solberg, USN, is dated 26 July 1944. It shows the ship's starboard side, horizontal surfaces, stern and superstructure ends.

Photograph from the Bureau of Ships Collection in the U.S. National Archives.

Online Image: 147KB; 1200 x 680 pixels

Reproductions of this image may also be available through the National Archives photographic reproduction system.
