Photo #: S-511-6

"Proposed Heavy Cruiser - CA2-D"


Preliminary design plan prepared for the General Board as part of the process leading to the Alaska class (CB1-6) large cruiser design.
This plan, dated 18 January 1940 and representing the largest size cruiser studied at this time, is for a ship of 38,700 tons standard displacement, with a main battery of twelve 12"/50 guns, a secondary battery of sixteen 5"/38 guns and a 212,000 horsepower powerplant for a speed of 33.5 knots. Ship's dimensions are: waterline length 850'; waterline beam 99'; maximum beam 104.5'; draft 31.5'. Anti-torpedo side protection, with four internal bulkheads, is shown in the hull section drawing at the lower left.
Scale of the original plan and elevation drawings is 1/32" = 1'. Scale of the hull section drawing is 1/16" = 1'.

The original plan is in the 1939-1944 "Spring Styles Book" held by the Naval Historical Center.

U.S. Naval Historical Center Photograph.

Online Image: 653KB; 3000 x 1875 pixels
