Photo #: S-511-33

"Mine Sweeper - Adaptation of PC 452 Type"


Preliminary design plan, probably prepared during consideration of what became the Adroit (AM-82) class.
This drawing, dated 6 January 1941, is for a 360-ton (full load displacement) vessel with a waterline length of 170 feet.
Scale of the original drawing is 1/8" = 1'.

The original plan is in the 1939-1944 "Spring Styles Book" held by the Naval Historical Center.

U.S. Naval Historical Center Photograph.

Online Image: 558KB; 3000 x 1975 pixels



Click on the small photograph to prompt a larger view of the same image.
