Photo #: S-511-34

"Proposed Mine Sweeper - Design Study"


Preliminary design plan, probably prepared during consideration of what became the Admirable (AM-136) class.
This drawing, dated 2 May 1941, is for a 750-ton (full load displacement) vessel with a length of 180 feet.
Scale of the original drawing is 1/8" = 1'.

The original plan is in the 1939-1944 "Spring Styles Book" held by the Naval Historical Center.

U.S. Naval Historical Center Photograph.

Online Image: 311KB; 2500 x 1305 pixels
