Photo #: S-584-103

Preliminary Design Plan for an Ammunition Ship for the Fiscal Year 1917 Shipbuilding Program... August 2, 1916


A preliminary design for an ammunition ship sent to the Secretary of the Navy for consideration in meeting the General Board’s characteristics of 7 October 1915 for ammunition ships. The design adopted the general form of Henderson (Transport # 1, see Photo # S-584-077) but modified it by moving machinery aft to facilitate cargo storage, cooling, and handling. This design, with a few modifications, was used as the basis for construction of Pyro (Ammunition Ship # 1) and Nitro (Ammunition Ship # 2).
This plan provides four 5-inch guns, turbine machinery for a speed of 16 knots, and an ammunition cargo capacity of 3,200 tons in a ship 460 feet long on the waterline, about 61 feet 1 inches in beam, and with a normal displacement of 10,600 tons.
Note: The original document was ink on linen (black on white).

The original plan is in the 1911-1925 "Spring Styles Book".

U.S. Naval Historical Center Photograph.

Online Image: 565KB; 2475 x 1090 pixels
