Photo # NH 55974:  USS Dale fitting out at Richmond, Virginia, 30 June 1902

Online Library of Selected Images:
-- U.S. NAVY SHIPS --

USS Dale (Destroyer # 4), 1902-1920 --
Construction Views


This page features all the views we have related to the construction of USS Dale (Destroyer # 4).

For more images related to USS Dale, see:

  • USS Dale (Destroyer # 4), 1902-1920.


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."

    Click on the small photograph to prompt a larger view of the same image.

    Photo #: NH 98133

    USS Dale
    (Destroyer # 4)

    View under the ship's after hull, showing machining operation on the starboard propeller strut. Photographed while Dale was on the building ways at the William R. Trigg Company shipyard, Richmond, Virginia, 30 June 1900.

    U.S. Naval Historical Center Photograph.

    Online Image: 105KB; 740 x 605 pixels


    Photo #: NH 98173

    USS Dale
    (Destroyer # 4)
    and
    USS Decatur (Destroyer # 5)

    Fitting out at the William R. Trigg Company shipyard, Richmond, Virginia, 29 June 1901.
    The photographer was standing on Dale's after superstructure, looking forward and to starboard, with Decatur at the right.

    U.S. Naval Historical Center Photograph.

    Online Image: 101KB; 740 x 610 pixels


    Photo #: NH 98135

    USS Dale
    (Destroyer # 4)

    View in the Crew Space, looking forward, with the supporting structure for the forward gun platform in the foreground. Photographed while Dale was fitting out at the William R. Trigg Company shipyard, Richmond, Virginia, 1 July 1901.
    Note wooden berths and chest lockers built in along the ship's side.

    U.S. Naval Historical Center Photograph.

    Online Image: 93KB; 740 x 610 pixels


    Photo #: NH 98134

    USS Dale
    (Destroyer # 4)

    View in the forward boiler room. Photographed while Dale was fitting out at the William R. Trigg Company shipyard, Richmond, Virginia, 3 July 1901.

    U.S. Naval Historical Center Photograph.

    Online Image: 103KB; 740 x 610 pixels


    Photo #: NH 98136

    USS Dale
    (Destroyer # 4)

    View in the port engine room, showing part of her port side triple-expansion steam engine. Photographed while Dale was fitting out at the William R. Trigg Company shipyard, Richmond, Virginia, 3 July 1901.

    U.S. Naval Historical Center Photograph.

    Online Image: 81KB; 740 x 605 pixels


    Photo #: NH 55974

    USS Dale
    (Destroyer # 4)

    Fitting out at the William R. Trigg Company shipyard, Richmond, Virginia, on 30 June 1902.

    U.S. Naval Historical Center Photograph.

    Online Image: 53KB; 740 x 590 pixels


    Photo #: NH 98138

    USS Dale
    (Destroyer # 4)

    Fitting out at the William R. Trigg Company shipyard, Richmond, Virginia. Photo is dated 30 June 1902.
    The three-masted schooner John S. Beacham is on the other side of Dale.
    Note men standing on Dale's forward gun platform, two of whom appear to be wearing some kind of "hard hat" protective headgear.

    U.S. Naval Historical Center Photograph.

    Online Image: 126KB; 740 x 605 pixels


    Photo #: NH 98137

    USS Dale
    (Destroyer # 4)

    View looking forward over the main deck, taken while Dale was fitting out at the William R. Trigg Company shipyard, Richmond, Virginia, 30 June 1902.
    Note gratings on her deck and piled against the after smokestack.

    U.S. Naval Historical Center Photograph.

    Online Image: 126KB; 740 x 610 pixels



    For more images related to USS Dale, see:

  • USS Dale (Destroyer # 4), 1902-1920.


    If you want higher resolution reproductions than the digital images presented here, see: "How to Obtain Photographic Reproductions."
