Photo #: NH 105046

Ship and Motor-Boat Bells


Figure 33 (page 174) of "The Naval Artificer's Manual", compiled and arranged by Assistant Naval Constructor (T) McCall Pate, USN, 1918. This page provides a drawing of a Motor Boat Bell, with its dimensions.
See Photo # NH 105043 for the first page of text concerning these bells, Photo # NH 105044 for a table of Weights, Tones, and Dimensions for Ship Bells, and Photo # NH 105045 for the second page of text, with a drawing of a Ship Bell.

U.S. Naval Historical Center Photograph.

Online Image: 135KB; 740 x 1225 pixels
